Hello everyone,
I am using the DUO-MODULE-01 board along with the CAM-GC2083 camera.
When I run the camera-test.sh script, I encounter the following error:
[SAMPLE_COMM_VPSS_Init]-28: CVI_VPSS_CreateGrp(grp:0) failed with 0xc0068004!
What is the cause of this issue, and how can it be resolved ??
I have successfully used this camera with the DUOS board, and it worked fine. However, it has problems with the DUO-MODULE-01 board.
[root@milkv-duo]~# camera-test.sh
[SAMPLE_COMM_SNS_ParseIni]-1950: Parse /mnt/data/sensor_cfg.ini
[parse_source_devnum]-1605: devNum = 1
[parse_sensor_name]-1686: sensor = GCORE_GC2083_MIPI_2M_30FPS_10BIT
[parse_sensor_busid]-1714: bus_id = 3
[parse_sensor_i2caddr]-1725: sns_i2c_addr = 37
[parse_sensor_mipidev]-1736: mipi_dev = 0
[parse_sensor_laneid]-1747: Lane_id = 2, 0, 1, -1, -1
[parse_sensor_pnswap]-1758: pn_swap = 0, 0, 0, 0, 0
MMF Version:7e0cc6a08-musl_riscv64
Create VBPool[0], size: (3110400 * 3) = 9331200 bytes
Create VBPool[1], size: (3110400 * 3) = 9331200 bytes
Create VBPool[2], size: (2764800 * 1) = 2764800 bytes
Total memory of VB pool: 21427200 bytes
Initialize SYS and VB
Initialize VI
ISP Vipipe(0) Allocate pa(0x97115000) va(0x0x3fc80de000) size(291120)
stSnsrMode.u16Width 1920 stSnsrMode.u16Height 1080 25.000000 wdrMode 0 pstSnsObj 0x3fc8f18878
[SAMPLE_COMM_VI_StartMIPI]-483: sensor 0 stDevAttr.devno 0
awbInit ver 6.8@2021500
0 R:1400 B:3100 CT:2850
1 R:1500 B:2500 CT:3900
2 R:2300 B:1600 CT:6500
Golden 1024 1024 1024
WB Quadratic:0
isWdr:0
ViPipe:0,===GC2083 1080P 30fps 10bit LINE Init OK!===
********************************************************************************
cvi_bin_isp message
gerritId: 36403 commitId: c69c5863e
md5: cab880835a2ad5184de5ed7762404b84
sensorNum 1
sensorName0 2083
PQBIN message
gerritId: 80171 commitId: 5c9d8fc5d
md5: ba5a510e093ad42db6788e6c2d13169e
sensorNum 3
sensorName0 2053
author: wanqiang.he desc: 思博慧CV1812H_GC2083_RGB_mode_V1.0.0
createTime: 2023-08-04 16:48:08version: V1.1
tool Version: v3.0.5.24 mode:
********************************************************************************
sensorName(0) mismatch, mwSns:2083 != pqBinSns:2053
[SAMPLE_COMM_ISP_Thread]-95: ISP Dev 0 running!
Initialize VPSS
---------VPSS[0]---------
Input size: (1920x1080)
Input format: (19)
VPSS physical device number: 1
Src Frame Rate: -1
Dst Frame Rate: -1
--------CHN[0]-------
Output size: (1920x1080)
Depth: 1
Do normalization: 0
Src Frame Rate: -1
Dst Frame Rate: -1
----------------------
--------CHN[1]-------
Output size: (1920x1080)
Depth: 1
Do normalization: 0
Src Frame Rate: -1
Dst Frame Rate: -1
----------------------
------------------------
[SAMPLE_COMM_VPSS_Init]-28: CVI_VPSS_CreateGrp(grp:0) failed with 0xc0068004!
init vpss group failed. s32Ret: 0xffffffff !
ISP Vipipe(0) Free pa(0x97115000) va(0x0x3fc80de000)
init middleware failed! ret=ffffffff
